Where a lightweight Fresnel spotlight using daylight characteristics with compact size and high efficiency is needed, ARRI True Blue D-Series Fresnels are the preferred choice. ARRI’s elegant modular construction, using corrosion-resistant aluminium extrusions and lightweight die castings, offers great structural strength and weather resistance. Together with ARRI flicker-free Electronic Ballasts, the rugged True Blue D-Series is ideal for all types of location lighting.

• Technical Data

• ARRI True Blue D12 set Package Contents
• 1x L1.33730.B D12 1200W Daylight Fresnel Lamphead, manual, blue/silver, int. (VEAM)
• 1x EB125P High Speed 1200W incl. 1000Hz Electronic Ballast
• 1x L2.75600.0 Head-to-Ballast cable 575/800/1200/1800 W, 7 m,International connector (VEAM)
• 1x L2.39870.0 4-leaf barndoor, True Blue (245 mm / 9.7″)

PRODUCT SPECIFICATION EB125P High Speed ballast 1200W incl. 1000Hz:

• Max Lamp Power    1200W
• Output Power Options    1.2kW, 800W, 575W
• Output Frequency Options    1000Hz, 300Hz, 100Hz, Silent Mode
• Input Voltage Range    95-265V AC
• Current Draw    6.1A@230V, 11.7A@120V
• Power Factor    >0.98
• DMX Built In    Yes
• Max Ambient Temperature    45°C/113°F
• Width    225mm/8.9″
• Height    115mm/4.5″
• Length    350mm/13.8″
• Weight    7.5kg/16.6lb
